Disabling port-based scheduling strategy:
SWITCH(config)# qos policy port-based delete port <1-MAX>
Enabling 802.1p-based scheduling strategy:
SWITCH(config)# qos policy 802.1p-based add port <1-MAX>
Disabling 802.1p-based scheduling strategy:
SWITCH(config)# qos policy 802.1p-based delete port <1-MAX>
Enabling IP TOS-based scheduling strategy:
SWITCH(config)# qos policy tos-diff add port <1-MAX>
SWITCH(config)#qos tos-diff-mode tos
Enabling IP DIFF-based scheduling strategy:
SWITCH(config)# qos policy tos-diff add port <1-MAX>
SWITCH(config)#qos tos-diff-mode diff-serv
Disabling IP TOS/DIFF-based scheduling strategy:
SWITCH(config)# qos policy tos-diff delete port <1-MAX>
7.2.5 Priority weight ratio configuration
In the WRR scheduling mode, the user can specify the priority weight ratio. In the default
state, the weight ratio of the 4 priority queues is as follows:
Scheduling ratio Priority
8 Highest
4 High
2 Low
1 Lowest
Configuring priority weight ratio:
SWITCH(config)# qos weight-config queue-0<1-55> queue-1<1-55> queue-2 <1-55>
queue-3 <1-55>
