Dimension One Spas Bay Collection - Manual (Page 42)

2004 Bay Collection
Owner’s Manual
JETS Button
The JETS Button turns the jet pump associated with the Massage Sequencer on
or off. The status light below the button will illuminate when the light is on. The
spa jet may be turned on/off with this button, or the one on the Top Side
Control. They work interchangeably.
SPEED Button
The SPEED Button is used to change the time interval between each step in the
sequences. The default time is 5 second intervals. The first push of the SPEED
Button will change the step interval time to 15 seconds, the second push will
change the intervals to 30 seconds, and the third push will reset the speed to 5
second intervals. The status light below the SPEED Button will blink at the
speed at which the system is operating. During a Pause condition the Speed status
light will be OFF.
BEGIN/PAUSE Button
The BEGIN/PAUSE Button is used to interrupt the massage sequence and to
start a particular sequence.
For example: If the user likes the jet massage at a particular moment during the
sequence, and wants to keep it for an extended period of time, the user may
press the BEGIN/PAUSE Button and the system will remain in the specific
configuration until the button is pushed again. The BEGIN/PAUSE Button
status light will be on when the system is in the Pause mode. During this mode,
the matrix of LED's will preview the sequence and the user may also push the
SEQUENCE Button to preview another sequence
SEQUENCE Button
The SEQUENCE Button is used to toggle between selected massage
sequences. When a sequence has been selected, the corresponding LED indicator
1-6 will light.
The default mode (all jets in the lounge operating) will not be indicated by a light.
Massage Zones
The Massage Zone Indicator Lights (Human Figure) will be lit to identify
which zone is currently active. More information on the muscle groups associated
with each zone is provided in the
Massage Zone Description section.
When a sequence is chosen, one or more LED in the figure will illuminate
showing the active zones in that sequence. When you have selected the massage
sequence you want, press the BEGIN/PAUSE Button to start your massage.
36
