2004 Bay Collection
Owner’s Manual
When the Jets 1&2 Button is pushed:
• The corresponding spa jet(s) pump is/are energized.
• The respective Status Indicator Light is illuminated.
• The pump speed is indicated in the lower left corner of the Digital
Display Window.
• A rotating swirl icon is displayed in the upper left corner of the Digital
Display Window. The rotation speed of the swirl will vary according to
the pump’s speed.
The first time the Jets 1&2 Button is pushed, Pump 1 will start on HIGH speed.
The second push starts Pump 2 to HIGH speed – now both pumps are running
on HIGH speed. The third push will turn Pump 1 off, leaving Pump 2 running on
HIGH speed. A fourth push will shut off Pump 2. Now both Pumps 1 & 2 will be
off.
Each time a Jets Button is pushed, the programmable automatic shut-off cycle is
activated. The jets may be programmed to shut off in 30, 45, or 60-minute
increments. The default time is 30 minutes. A progress bar, indicating the time
remaining before the pump will turn off, is displayed immediately following the
pump speed message. The pump automatic shut-off cycle is programmed
separately. All pumps are controlled by the same automatically shut-off cycle.
JETS 1&2 Button
The automatic shut-off cycles are a safety device that will reduce
wear and tear on your equipment and reduce energy costs by
ensuring that your pumps don’t run constantly.
Additionally, this feature allows for convenient filtration immediately
after use of the hot tub by letting you “push the Jets Button” as you
leave to get an additional 30/45/60 minutes of filtering.
Jet Pump 3 Button
When the Jets 3 Button is pushed:
• Pump 3 is started on HIGH speed. A 2 nd push will turn the pump off.
• The Status Indicator Light for Jet Pump 3 is illuminated.
• The pump speed is indicated in the lower left corner of the Digital
Display Window.
• A 2 nd rotating swirl icon is displayed in the upper left corner of the
Digital Display Window.
25
