Operation

Operating Manual PSSu E F AI I(T)(R)
21981EN05

28

7.2.2

Display elements for input status

The input is assigned an LED for displaying the input status (LED “I0”).

11

21

I0

Err

I0

LED

Meaning

Designa
tion

Colour

Status

Signal

Input

Ter
minal

I0

No signal
detected

I0
(Input 1)

11/14

Green

Signal
detected
