Technical Details
Operating Manual PSSu H PLC1 FS SN SD(­T)(­R)
21939­EN­10 39
Environmental data 312070 314070 315070
Max. operating height
above sea level
2000 m 5000 m 2000 m
Airgap creepage
In accordance with the
standard
EN 60664­1 EN 60664­1 EN 50124­1
Overvoltage category II II OV2
Pollution degree 2 2 PD1
Protection type
In accordance with the
standard
– – EN 60529
Mounting area (e.g.
control cabinet)
IP54 IP54 IP51
Housing IP20 IP20 IP20
Mechanical data 312070 314070 315070
Material
Bottom PC PC PC
Conductor cross section
with screw terminals
1 core flexible 0,25 ­ 2,50 mm², 24 ­ 12
AWG 0,25 ­ 2,50 mm², 24 ­ 12
AWG 0,25 ­ 2,50 mm², 24 ­ 12
AWG
2 core with the same
cross section, flexible
with crimp connectors,
no plastic sleeve
0,25 ­ 1,00 mm², 24 ­ 16
AWG 0,25 ­ 1,00 mm², 24 ­ 16
AWG 0,25 ­ 1,00 mm², 24 ­ 16
AWG
2 core with the same
cross section, flexible
without crimp connect­
ors or with TWIN crimp
connectors
0,20 ­ 1,50 mm², 24 ­ 16
AWG 0,20 ­ 1,50 mm², 24 ­ 16
AWG 0,20 ­ 1,50 mm², 24 ­ 16
AWG
Torque setting with screw
terminals
0,50 Nm 0,50 Nm 0,50 Nm
Connection type Spring­loaded terminal,
screw terminal Spring­loaded terminal,
screw terminal Spring­loaded terminal,
screw terminal
Mounting type plug­in plug­in plug­in
Conductor cross section
with spring­loaded termin­
als: Flexible with/without
crimp connector
0,20 ­ 2,50 mm², 24 ­ 12
AWG 0,20 ­ 2,50 mm², 24 ­ 12
AWG 0,20 ­ 2,50 mm², 24 ­ 12
AWG
Stripping length 9 mm 9 mm 9 mm
Dimensions
Height 125,6 mm 125,6 mm 125,6 mm
Width 130,0 mm 130,0 mm 130,0 mm
Depth 83,7 mm 83,7 mm 83,7 mm
Weight 335 g 378 g 378 g
The standards current on 2009­07 apply.
