PNOZ c2
Operating Manual PNOZ c2
22212­EN­02 11
Times 710002
Switch­on delay
With automatic start typ. 200 ms
With automatic start max. 550 ms
With monitored start with rising edge typ. 20 ms
With monitored start with rising edge max. 50 ms
Delay­on de­energisation
With E­STOP typ. 5 ms
With E­STOP max. 12 ms
Recovery time at max. switching frequency 1/s
After E­STOP 300 ms
Waiting period with a monitored start
With rising edge 300 ms
Min. start pulse duration with a monitored start
With rising edge 30 ms
Supply interruption before de­energisation 20 ms
Simultaneity, channel 1 and 2 ∞
Environmental data 710002
Climatic suitability EN 60068­2­78
Ambient temperature
Temperature range ­10 ­ 55 °C
Storage temperature
Temperature range ­40 ­ 85 °C
EMC EN 60947­5­1, EN 61000­6­2, EN 61000­6­4
Vibration
In accordance with the standard EN 60068­2­6
Frequency 10,0 ­ 55,0 Hz
Amplitude 0,35 mm
Airgap creepage
In accordance with the standard EN 60947­1
Overvoltage category III
Pollution degree 2
Rated insulation voltage 250 V
Rated impulse withstand voltage 6,00 kV
Protection type
Mounting area (e.g. control cabinet) IP54
Housing IP40
Terminals IP20
Mechanical data 710002
Mounting position Any
Mechanical life 10,000,000 cycles
Material
Bottom PC
Top PC
Connection type Spring­loaded terminal
Mounting type Fixed
