PNOZ c1
Operating Manual PNOZ c1
22197­EN­02 12
Times 710001
Supply interruption before de­energisation 20 ms
Simultaneity, channel 1 and 2 ∞
Environmental data 710001
Climatic suitability EN 60068­2­78
Ambient temperature
Temperature range ­10 ­ 55 °C
Storage temperature
Temperature range ­40 ­ 85 °C
EMC EN 60947­5­1, EN 61000­6­2, EN 61000­6­4
Vibration
In accordance with the standard EN 60068­2­6
Frequency 10,0 ­ 55,0 Hz
Amplitude 0,35 mm
Airgap creepage
In accordance with the standard EN 60947­1
Overvoltage category III
Pollution degree 2
Rated insulation voltage 250 V
Rated impulse withstand voltage 6,00 kV
Protection type
Mounting area (e.g. control cabinet) IP54
Housing IP40
Terminals IP20
Mechanical data 710001
Mounting position Any
Mechanical life 10,000,000 cycles
Material
Bottom PC
Top PC
Connection type Spring­loaded terminal
Mounting type Fixed
Conductor cross section with spring­loaded terminals:
Flexible with/without crimp connector
0,25 ­ 1,50 mm², 24 ­ 16 AWG
Spring­loaded terminals: Terminal points per connec­
tion
1
Stripping length 9 mm
Dimensions
Height 105,0 mm
Width 22,5 mm
Depth 100,0 mm
Weight 160 g
The standards current on 2011­11 apply.
