PNOZ c1
Operating Manual PNOZ c1
22197­EN­02 11
Relay outputs 710001
Utilisation category
In accordance with the standard EN 60947­5­1
Auxiliary contacts, AC15 at 230 V
Max. current 5,0 A
Auxiliary contacts, DC13 (6 cycles/min) at 24 V
Max. current 5,0 A
Safety contacts, AC15 at 230 V
Max. current 5,0 A
Safety contacts, DC13 (6 cycles/min) at 24 V
Max. current 5,0 A
Utilisation category in accordance with UL
Voltage 240 V AC G.U. (same polarity)
With current 6,0 A
Voltage 24 V DC G. U.
With current 6,0 A
Contact fuse protection, external safety contacts
In accordance with the standard EN 60947­5­1
Blow­out fuse, slow 6 A
Circuit breaker, 24V AC/DC, characteristic B/C 6 A
Contact fuse protection, external auxiliary contacts
Blow­out fuse, slow 6 A
Circuit breaker, 24 V AC/DC, characteristic B/C 6 A
Contact material AgCuNi + 0,2 µm Au
Conventional thermal current while loading sev­
eral contacts 710001
Ith per contact at UB DC
Conv. therm. current with 1 contact 6,00 A
Conv. therm. current with 2 contacts 6,00 A
Conv. therm. current with 3 contacts 5,00 A
Times 710001
Switch­on delay
With automatic reset typ. 250 ms
With automatic reset max. 450 ms
With automatic reset after power on typ. 250 ms
With automatic reset after power on max. 450 ms
With manual reset typ. 125 ms
With manual reset max. 450 ms
Delay­on de­energisation
With E­STOP typ. 15 ms
With E­STOP max. 30 ms
With power failure typ. 60 ms
With power failure max. 100 ms
Recovery time at max. switching frequency 1/s
After E­STOP 300 ms
After power failure 300 ms
