WARNING
During the following steps, the motor protector may
open.Wait about 20 minutes for protector to reset.
1. Adjusting the
“
OPEN
”
limit switch (Fig. 8-1).
•
Run door to open position by pushing wall control.
•
Locate curved
“
OPEN
”
limit adjustment slot on
back of power head.
•
Look into slot for pinion screw.
•
Insert a screwdriver and turn pinion screw.
–
clockwise to open more.
–
counterclockwise to open less.
2. Test door operator. Use wall control to run
door open and close.
3. Repeat step as necessary to properly set
“
OPEN
”
limit switch.
4. Adjust the
“
CLOSE
”
limit switch (Fig. 8-1).
•
Run door fully closed by pushing wall control.
•
Locate curved
“
CLOSE
”
limit adjustment slot on
back of power head.
•
Look into slot for pinion screw.
•
Insert a screwdriver and turn pinion screw.
–
counterclockwise to close more.
–
clockwise to close less.
5. Test door operator. Use wall control to run door
open and close
6. Repeat step as necessary to properly set
“
CLOSE
”
limit switch
7. Perform CONTACT REVERSE
Moving door can cause serious injury or death
•
Keep people clear of opening while door is moving.
•
Do Not allow children to play with remote controls.
If safety reverse does not work properly:
•
Close door and disconnect operator using
emergency release.
•
Do not use door operator or remote controls
•
Refer to door and door operator owner
’
s
Manuals before attempting any repairs
NNOOTE: Facttoorryy seets diffffeerent cooddees ffoorr eeach remootte
ccontrol..
RReemote coonnttrroolls wiill nnoott wwork iff SSTTBB
’
s mmaalffunctiion
WWhenn pprrooggrraammiinngg remootte control kkeeep att leeasst 24
iinchhees awayy from anntteenna..
1. Program one-button remote (Fig. 9-1)
•
Locate learn code button and learn indicator on
power head.
–
On back of power head.
•
Press and release learn code button on
power head.
–
LED on power head blinks 2 times per second.
One-Button Remote Control* Multi-Button Remote Control*
Complete with
Battery
Actual picture may vary by model
N C C ASS 2 1
2
3
4
5
6
E
U H
U T
A E
E M
I IT
ET
P N
O CE
L
O N L E RN E
OM OTE: E E C T O
LO E
ORE OP N
MO E
CL S PEN LI IT ADJUST ENT 5 2 3 7 4 5 21 6
M RE M RE
L M T A J S ME T L S N P SH
L I S O S T
C A S 2 N C
STEALTH
PRO-MAX
Fig. 9-1
24
888
....
FINNEE LLIMIITT SSWITTCH ADJUSTTMEENT
FFOOR HELLP--1.8000.3354.36443 OOR GENIEECOMPANY.COOM
MORE MORE
L MIT ADJUSTMENT
CLOSE OPEN
PUSH
L MITS
TO SET
4
3
2
1
CLASS 2
NEC
C O E O E
U
TO S
LIMIT ADJUSTMENT
CLOSE
MORE
OPEN
MORE
Fig. 8-1
99
....
RREEMMOOTTEEEE CCCCOOOONNTTRROOLLLSS
* Remotes vary depending on model.Your operator will
have one or the other.
(continued on next page)
