Things to consider if you are planning to
“
do-it-yourself.
”
Whether you are replacing an existing garage door operator or installing an operator in
your garage for the first time, there are some pre-installation issues which need to be
addressed. They are as follows:
TThheeee GGeenniieeee CCoooommppppaannnnyy rreeccoooommmmmmeeennddddsss tthhaatt yyoouu rreeaaadddd aaanndddd ffuullllllyy uunnnnddeerrsssstttaanndd aallll
infforrmatiion and innssttrucctionns conttaainneedd hheerreinn beefforre cchhooosinngg aa
“
DDoo--IItt--Yoouursself
”
iinnssssttaallllaaaattiioonnnn.. AAnnnnyy qquuuueessssttttiioooonnss sssshhhoooouulldddd bbbeeee ddiiirrrreeeecctteedddd ttttooo tthhee GGGeenniieeee CCoooommpppaannyy oooorrr aann aauuuutthhoorrriizzzzeedd
Genie DDealleerr.
6
To avoid damage to your door and/or
operator, make sure you disable any door
locks prior to installing your operator .
2
PPRREEEE----IIIINNNSSSSTTTTAALLLLLLAATTTTIIOOONNNN CCHHHHEECCKKK LLIIIISSTT
FORR HELP-11.8800.35544.336433 OR GEENIIECCOOMPPANYY.CCOM
1
Check your ceiling where the power
head of your new unit will be mounted
Plan how you will be mounting the power head
It is possible that ceiling joists may not be in the
exact position needed with respect to the garage
door operator In any case it may be necessary
to add an additional bracket and fasteners (not
included with your new door operator kit)
2
Check the wall directly above the garage
door . The door operator
’
s header bracket
must be securely fastened to this wall Insure
that the structure will provide a strong mounting
location
3
Check to see if the mounting location
for the Safe-T-Beam
®
System
(
STB
)
is
clear from obstruction and has a wood
surface available for attaching the STB brack-
ets . The brackets may also be attached to con-
crete if necessary but extra tools and special
fasteners (not supplied) will be required
NOTE: 1-1/2
" “
STB
”
bracket adapters are
available through your local Genie Dealer.
4
Is your garage door made of
light-weight steel, aluminum, fiberglass
or glass panels ? Additional support bracing
must be added to these type doors If this is the
case please contact the door distributor or
manufacturer so that they can furnish you with a
“
bracing kit
”
7
Insure that your door is properly balanced
and moving freely. SEE WARNING BELOW
If your door sticks, binds, or is out of
balance, have it adjusted by a professional.
Door springs, cables, pulleys, brackets and
associated hardware are under extreme
tension and can cause serious injury or
death.
WARNING
(The issue numbers below refer to the circled numbers in the illustrations on page 3.
)
8
(NOT SHOWN) If your garage does not have
a separate entry door, you might want to
consider an emergency release kit (GER-2) for
installation on your garage door See page 30
DO NOT USE EXTENSION CORD!
Extension cords can cause dangerous
overheating conditions.
DO NOT USE PORTABLE GENERATOR!
This product is designed to operate on
standard house current. Do not use
alternate power supplies.
WARNING
5
You need a 110-120 Volt power supply
available . If you plan to plug the unit into a
standard electrical outlet is one available? The
outlet should be no more than about 3 feet from the
power head once it is mounted (The cord is 4 ft in
length ) SEE WARNING BELOW
