21
7 SERIES 50Hz 700A11 INSTALLATION MANUAL
Model
Variable Speed
009 012 015
Compressor (1 each) Variable Speed Scroll
Factory Charge R-410A, kg Vertical 2.69 3.40 3.96
Factory Charge R-410A, kg Horizontal 2.69 3.85 4.19
ECM Blower Motor & Blower
Blower Motor Type/Speeds ECM Variable Speed
Blower Motor - W ECM 373 746 746
High Static Blower Motor - W ECM 746 N/A N/A
Blower Wheel Size (Dia x W), mm ECM 279 x 254 279 x 254 279 x 254
High Static Blower Wheel Size - [Dia. x W], mm ECM 279 x 254 N/A N/A
Coax and Water Piping
Water Connections Size - Swivel - in [mm] 1 [25.4] 1 [25.4] 1 [25.4]
HWG Connection Size - Female Sweat I.D. - in [mm] 1/2 [12.7] 1/2 [12.7] 1/2 [12.7]
Coax & Piping Water Volume - l 6.1 6.1 8.7
Vertical
Air Coil Dimensions (H x W), mm 813 x 635 813 x 635 914 x 635
Air Coil Total Face Area, m 2 0.570 0.570 0.641
Air Coil Tube Size, mm 9.5 9.5 9.5
Air Coil Number of rows 3 3 4
Filter Standard - 51 mm Pleated MERV 11 Throwaway, mm 813 x 762 813 x 762 914 x 762
Weight - Operating, kg 160 164 175
Weight - Packaged, kg 169 173 184
Horizontal
Air Coil Dimensions (H x W), mm 508 x 1016 508 x 1016 508 x 1143
Air Coil Total Face Area, m 2 0.570 0.570 0.641
Air Coil Tube Size, mm 9.5 9.5 9.5
Air Coil Number of rows 3 3 4
Filter Standard - 51 mm Pleated MERV 11 Throwaway, mm
1 - 508 x 508
1 - 508 x 559
1 - 508 x 508
1 - 508 x 559
1 - 508 x 635
1 - 508 x 559
Weight - Operating, kg 176 180 188
Weight - Packaged, kg 189 193 202
5/13/13
Physical Data
