Page 20
20
7 SERIES 50Hz 700A11 INSTALLATION MANUAL
2 ft [61 cm]
Primary Service Access
B
C
2.1in
[5.4cm]
H
L
O
N
M
S
R
Q
P
MOUNT (2) HANGER BRACKETS
AS SHOWN TO ALLOW ACCESS
TO FILTER
AS SHOWN LR UNIT (RR UNIT ON OPPOSITE SIDE—SAME DIMENSIONS)
SIDE DISHCARGE VIEW
END VIEW
TOP VIEW
A
S
FRONT VIEW
D
E
F
G
I K J
1.9in
[4.8cm]
O
L
Units Not Shown Above
L
O
Right Return End Discharge
cm
7.1
11.8
Right Return Side Discharge
cm
12.4
17.5
Left Return End Discharge
cm
12.4
19.4
Left Return Side Discharge
cm
7.1
17.5
Horizontal
Models
Overall Cabinet
Water Connections
Electrical Connections
Discharge Connection
duct flange installed
(± 2.54mm)
Return Connection
using std deluxe filter rack
(± 2.54mm)
I
12.7mm
cond
J
12.7mm
cond
K
19.05mm
cond
A
Width
B
Depth
C
Height
D
In
E
Out
F
HWG
In
G
HWG
Out
H
Cond-
ensate
Loop
Water
FPT
HWG
Sweat
(I.D.)
Low
Voltage
Ext
Pump
Power
Supply
L
M
Supply
Height
N
Supply
Depth
O
P
Q
Return
Depth
R
Return
Height
S
009
cm.
65.0
195.6
54.1
5.8
18.5
40.4
48.0
2.0
25.4mm
Swivel
12.7mm
Female
36.3
24.9
31.2
See
Chart
34.5
33.5
See
Chart
7.1
102.6
48.0
3.3
012
cm.
65.0
195.6
54.1
5.8
18.5
40.4
48.0
2.0
36.3
24.9
31.2
34.5
33.5
7.1
102.6
48.0
3.3
015
cm.
65.0
208.3
54.1
5.8
18.5
40.4
48.0
2.0
36.3
24.9
31.2
34.5
33.5
7.1
115.3
48.0
3.3
Condensate is 19.05mm PVC female glue socket and is switchable from side to front
Unit shipped with deluxe 5.08cm (field adjustable to 2.54cm) duct collar/filter rack extending from unit 8.255cm and is suitable for duct connection.
Discharge flange is field installed and extends 25.4mm from cabinet
Decorative molding and/or water connections extend 30.5mm beyond front of cabinet.
Louvered vents in the compressor section right side access panel extend 12.7 mm from side of cabinet. Allow clearance for venting.
5/29/13
Horizontal Dimensional Data
