Installation Instructions
32-Channel Analog Input Module
Quantum Series 140 AxI 05x 00sc

48

Engineering units

mV, mA

Resolution

10 bits to 22 bits (frequency dependent)

Input Filter

10Hz, 50Hz, 60Hz, 1KHz
Digital Notch Filter, Programmable in groups of 8 inputs.

Channel Update Time

See Installation Guide for Channel Update Time chart vs
filter selection

Single Channel

12 ms to 308 ms (frequency dependent)

32 Channel

384 ms to 9.9 sec (frequency dependent)

Isolation

Channel to Rack

500 VAC Continuous

Optical & magnetic

Channel to Channel

0 volts, non-isolated within a group

Group to Group

±15V
