Installation Instructions
32-Channel Analog Input Module
Quantum Series 140 AxI 05x 00sc

5

Chapter 2
MODULE SETUP FOR MODSOFT

2.1

General Information

Six steps must be performed in order to fully configure the Quantum
system in preparation for using the AxI 05x 00sc:

Step 1: Modsoft programming software must be updated so that the

140 AxI 05x 00sc is recognized in the software (see Section 2.2).

Step 2: Select the appropriate slot location using the Modsoft I/O map.

Choose the first 3x and 4x level registers to be used in the
system for the module’s data, configuration and status informa-
tion (see Section 2.3).

Step 3: Zoom screens for the module must be set to match application

requirements (see Section 2.4).

Step 4: The 4x configuration register must be set to meet application

requirements (see Section 4.1).

Step 5: Module status information is available to you. The various

options must be understood and chosen to meet your application
requirements (see Section 4.2 and Section 4.3).

Step 6: Ladder rungs must be written to demultiplex the incoming 8 data

registers to 32 user selected data registers (see Section 6.3).
