Installation Instructions
32-Channel Analog Input Module
Quantum Series 140 AxI 05x 00sc
7
4x
Configuration Word
3x + 0
Data Input Word 1
3x + 1
Data Input Word 2
3x + 2
Data Input Word 3
3x + 3
Data Input Word 4
3x + 4
Data Input Word 5
3x + 5
Data Input Word 6
3x + 6
Data Input Word 7
3x + 7
Data Input Word 8
3x + 8
Status Word
The AxI 05x 00sc multiplexes 32 channels of data into four groups of
eight channels. Each group can be selected through the 4x Configuration
Word or can automatically sequence through all four groups of channels.
Group 1
Chn 1-8
3x + 0
Data Input Word 1
3x + 1
Data Input Word 2
Group 2
Chn 9-16
3x + 2
Data Input Word 3
3x + 3
Data Input Word 4
Group 3
Chn 17-24
3x + 4
Data Input Word 5
3x + 5
Data Input Word 6
Group 4
Chn 25-32
3x + 6
Data Input Word 7
3x + 7
Data Input Word 8
2.4
Zoom Screen Configuration
For Zoom Screen operation, please refer to Modicon’s Modsoft Program-
mer User Manual.
Note: To enter zoom screens from the I/O map menu, highlight the module entry and press the
keys
Most of the module setup will be done through the Modsoft zoom
screens. The zoom screen setup establishes the following parameters:
• Calibration rate
• Filter Frequency Selection
• Input Data Format
• Input Range
