background image

Installation Instructions
32-Channel Analog Input Module
Quantum Series 140 AxI 05x 00sc

47

Chapter 8
SPECIFICATIONS

Number of Channels

32

Input Registers Required

9

Output Registers Required

1

Input Configuration

32 inputs configured in groups of 8 channels per common

LEDs

35 - One each for Ready (Green), Active (Green), Fault
(Red), 32 Channel (Green)

Voltage Range

±10VDC, 0 to 10VDC, 0 to 5VDC, 1 to 5VDC

Current Range

4 to 20mA, 0 to 20mA

Impedance, input

Voltage Mode: 10 Megohms, min.
Current Mode: 350 ohms

Fault Detection

Over & under range status bits, for all current and voltage modes.

CMRR

90 dB

Power Requirements

630 mA @ 5 V maximum

Max Input Current

±50 mA continuous

Max Input Voltage

± 20VDC continuous

Agency Approvals

UL, CUL Class 1 Div II, CE, FCC Class A

Accuracy

Note: Accuracy is dependent on the filter frequency
selection, range selection, data format, and input noise.

Voltage Typ

±0.03% of full scale typical @ 25°C.

Voltage Max

±0.05% of full scale Maximum @ 0 to 60°C.

Current Typ

±0.05% of full scale typical @ 25°C

Current Max

±0.10% of full scale maximum @ 0 to 60°C

Miscellaneous

Display format

12 bit integer, 16 bit integer, 15 bit signed integer,
10000 count DVM
