User's Manual 0300215-03 Rev. A
Chapter 6
Module Data, Status, and
Channel Configuration
After installing the 1769sc-IF4IH isolated HART input module, you must configure it for
operation, usually using the programming software compatible with the controller (for
example, RSLogix 500 or RSLogix 5000). Once configuration is complete and reflected
in the ladder logic, you need to operate the module and verify its configuration.
This chapter contains information on the following:
•
Module memory map
•
Accessing input image file data ·
•
Configuring channels
•
Determining effective resolution and range
•
Determining module update time
Section 6.1
Module Memory
Map
The module uses fifty input words for data and status bits (input image), twenty four
output words, and thirty four configuration words.
Figure 6-1 (Module Memory Map)
NOTE: Not all
controllers support
program access to the
configuration file. Refer
to your controller’s user
manual.
slot e
Input Image File
Input Image
72 Words
Memory Map
Word 0: Channel 0 Data Word
Word 1: Channel 1 Data Word
Word 2: Channel 2 Data Word
Word 3: Channel 3 Data Word
Word 4: Time Stamp Value
Word 5: General Channel Status
Word 6: Process & Range Alarms
Word 7: Pad
Words 8..27: HART Packet Data
Word 28: ScanMSG Slave Control
Word 29: ScanMSG Response Size
Words 30..49: ScanMSG Response Buffer
Bit 15 Bit 1
slot e
Configuration File
Configuration
34 Words
Words 2..7: Channel 0 Configuration
Words 8..13: Channel 1 Configuration
Words 14..19: Channel 2 Configuration
Words 20..25: Channel 3 Configuration
Bit 15 Bit 1
Word 1: Module Configuration
Word 0: Real Time Sample
slot e
Output File
Output
46 Words
Word 2: ScanMSG Master Control
Word 3: ScanMSG Request Size
Word 4..23: ScanMSG Request Buffer
Bit 15 Bit 1
Word 1: Last Packet Scanned
Word 0: Unlatch Alarms/HART Suspend
Word 26: Ch0 Slot Variables 0 & 1
Word 27: Ch0 Slot Variables 2 & 3
Word 28: Ch1 Slot Variables 0 & 1
Word 29: Ch1 Slot Variables 2 & 3
Word 30: Ch2 Slot Variables 0 & 1
Word 31: Ch2 Slot Variables 2 & 3
Word 32: Ch3 Slot Variables 0 & 1
Word 33: Ch3 Slot Variables 2 & 3
Words 50..71: Reserved
Word 24..45: Reserved
