CUSTOM
CUSTOM allows the user to create a custom MIDI string of any five MIDI
commands for each preset. All five commands will be sent whenever the
preset is recalled.
CUSTOM, Page 1 of 2 - Command Selection
The first page of the CUSTOM program, Command Selection, allows for
the selection of MIDI commands and the order in which they are to be
transmitted once the preset has been recalled.
To access CUSTOM:
() To access CUsTOM, press the "2nD" button to activate the second-
ary button functions.
() Press the "CUsTOM" button. The l.e.D. above the "CUsTOM" but-
ton will flash and the MIDI Raider will display the first page of the
CUsTOM program.
To create a MIDI command string:
() Use the "InC" and "DeC" switches directly below the preset number
currently displayed to select the desired preset.
() Use the "InC" and "DeC" switches directly below the command
number currently displayed to select the desired command number.
() Use the "InC" and "DeC" switches directly below the MIDI com-
mand currently displayed to select the desired MIDI command (see
CUSTOM, page 2).
MIDI Message Abbreviations:
nOFF>
(note Off)
n On>
(note On)
KPrs>
(Key Pressure)
C CH>
(Control Change)
P CH>
(Program Change)
CPrs>
(Channel Pressure)
PBen>
(Pitch Bend)
T ClK
(Timing Clock)
sTarT
(start)
COnTU
(Continue)
sTOP
(stop)
aCTsn
(active sensing)
sYsrs
(system reset)
MTC>
(MIDI Time Code)
sGPP>
(song Position Pointer)
sGsl>
(song select)
T reQ
(Tune request)
nOne
(none)
Note:
MIDI commands which are
followed by a “>” symbol
require additional information
on the next CUSTOM page
before the message will
be stored in this page (see
CUSTOM, Page 2).
