30
MIDI
The MIDI program provides access to the MIDI features of the MIDI raider
footswitch. Use the MIDI program to assign each of the following:
Programmable patch changes;
Control numbers and channels to instant access switches and pedals;
Control values to instant access switches and pedals;
Instant access switch types;
Program change status;
Program mapping; and,
MIDI Raider MIDI receive channel
Upon accessing MIDI, the first page of the MIDI program, Programmable
Patch Changes, will automatically be displayed.
MIDI, Page 1 of 7 - Programmable Patch Changes
The first page of the MIDI program, Programmable Patch Changes, allows for
the assignment of up to 16 programmable patch changes for each MIDI raider
preset. Programmable patch changes are sent when an MIDI raider preset is
recalled to aid in selecting the desired preset on a remote MIDI receiving unit.
This page of the MIDI program allows for the assignment of program changes
to MIDI raider presets. The programmable patch changes are arranged by
patch number.
To access MIDI:
() To access MIDI, press the "2nD" button to activate the secondary but-
ton functions.
() Press the "MIDI" button. The L.E.D. above the "MIDI" button will flash
and the MIDI Raider will display the first page of the MIDI program.
Pressing the "" button while in the 2nD mode accesses each succes-
sive page.
To assign programmable patch changes:
() Use the "InC" and "DeC" switches directly below the displayed preset
number to select the preset to which patch changes will be assigned.
() Use the "InC" and "DeC" switches directly below the displayed MIDI
channel to select the MIDI channel to send a particular program change
on. note: If names have been assigned to MIDI channels (as described
in SETUP, Page 5), then the name of each channel will be displayed,
instead of the channel number.
() Use the "InC" and "DeC" switches directly below the currently dis-
played patch change to select the patch change that is to take place on
the given MIDI channel for the selected preset. MIDI program changes
are sent when the preset is recalled.
Repeat steps  through  for each of the desired presets.
Note:
If the starting preset
number is set to “0”
(as described in
SETUP, page 6), then
program changes
0-127 can be accessed.
If the starting preset
number is set to “1”,
then program changes
1-128 can be accessed.
