RVC 2-25 CD&
5 Set-up and connection
28
Version 11/2008, Rev. 2.2 of 04/12/2013 • sb
Translation of the original operating manual
Pos: 98 / 200 Christ /37 0 RVC-BA (STANDARDM ODULE)/ 050 Au fstellu ng u nd Ans chluss/ 050 -00 40 V akuu mve rbind ung en (au ßer 2- 18 HCL ) @ 12\ mod _13 3697 593 969 9_6 8.do cx @ 6 447 1 @ 3 @ 1
5.4 Vacuum connections
The vacuum connection is realised by way of a vacuum hose with standard
flange connections, clamping rings, or chains, and centring rings.
NOTE
The small flange connections must be installed correctly in order to
prevent leaks (see chapter 7.1.5 - "Small flange connections ").
1
Centring ring
2 Clamping ring
3 Flange connection
Fig. 1: Connecting pieces for vacuum connection
