RVC 2-25 CD&
5 Set-up and connection
Version 11/2008, Rev. 2.2 of 04/12/2013 • sb
27
Translation of the original operating manual
Connecting combinations:
1. Connection for aeration and air injection with ambient air (state of
delivery)
1 Fastener for non-required connection element; here: hose nozzle
2 Air filter
3 Aeration hose connection
2. Connection for aeration with ambient air and air injectio" with inert gas
1 Fastener for non-required connection element; here: air filter
2 Air injection hose nozzle
3 Aeration hose connection
3. Connection for aeration and air injection with inert gas
1 Fastener for non-required connection element; here: air filter
2 Air injection hose nozzle
3 Aeration hose connection
CAUTION
If gas (e.g. inert gas) is supplied through the hose nozzle for aeration or for
“air injection”, the threads of the hose nozzles must be sealed with thread
sealant, e.g. Loctite
® 542 (Loctite ® part number: 54223, bottle with 10ml).
