Chapter 5: Using The Cabinet
Product Service 1-800-522-7658 34
Original instructions
Information Center
The Information Center is an LCD display located on the right side wall at
eye level. When the blower is started, if the Axiom is configured to be
connected to an exhaust system, Figure 5-2a will appear for 60 seconds while
the unit initiates operation.
If the unit is not connected to an exhaust system, screen 5-2b will appear for
the first 60 seconds of operation. After 60 seconds, the default display screen
will appear. The display provides a clock, the life remaining for both filters,
the cabinet’s current status, inflow velocities (if equipped with the optional
airflow sensor), as shown in Figure 5-3. In the event of an alarm, the
Information Center will immediately display a context sensitive display
indicating the cause of the alarm, and possible solutions, as shown in Figure
5-4.
The display will enter sleep mode, turning itself off, one minute after the
blower is turned off or the sash is closed.
Clock
Filter Life
10:03
Figure 5-2b
Figure 5-2a
Figure 5-3
100% 100%
10:03
