Chapter 3: Getting Started
Product Service 1-800-522-7658 18
Original instructions
Disconnecting the Axiom from an Exhaust System
c)
Mechanical configuration
1.
Using an appropriate ladder or platform, remove the exhaust
cover panel(s) on the top left side of the exhaust cover, and install
them on the studs on the right side. Hand tighten the wing nuts to
secure it, as shown in figure 3-2a.
2.
Disconnect the Axiom’s exhaust collar from the exhaust system,
and cap the building’s exhaust connection in a way that meets all
appropriate codes and regulations. Leave the Axiom’s exhaust
collar open to allow for unrestricted airflow out of the unit.
Exhaust cover removed from left
side, exposing exhaust outlet
Exhaust cover installed on right side
to store for future reconfiguration
Figure 3-2a
