Saving and Recalling Power/Loss Values
Power Meter/Light Source/Optical Loss Test Set 41
Saving, Recalling and Deleting Data
To recall saved data:
1. From normal operating mode, hold down
for a few seconds. The Recall indicator
is displayed with the cable name, then the
last saved value and its fiber ID.
2. When fiber ID is displayed, hold down
for a few seconds to return to the cable
name list. Select the cable in which you want to recall saved data by
using
and to move forward or backward. The last saved
value in the selected cable and its fiber ID will be displayed after 3
seconds.
3. View values you want by using and to move forward or
backward in saved data. You can also change the units by pressing
.
4. Press to return to normal mode.
I
MPORTANT
When the power meter is connected to the fiber or DUT, you must
wait until at least one loss measurement is displayed on the power
meter before pressing the
button.
Once you have pressed the button, you must wait until the Store
indicator on-screen disappears before disconnecting the power
meter or light source to test the next fiber or DUT.
When in Auto-Switching mode, it is important NOT to disconnect
the power meter or light source from the fiber or DUT before the
storage sequence is complete. The storage sequence is complete
when the Store indicator turns off.
The storage process will save the upcoming values, not the
preceding ones.
