Getting Started
Power Meter/Light Source/Optical Loss Test Set 13
Activating Automatic Shutdown (Auto-Off)
Activating Automatic Shutdown (Auto-Off)
When auto-off is activated, the unit will turn off
after 10 minutes of idle time.
Auto-off is activated by default when you turn
on the unit.
To deactivate/reactivate auto-off:
When unit is on, press
.
Turns unit on/off
Controls auto-off
Exits special modes
PRESS: Switches between
Power, Hold Min, Hold Max
HOLD: Backlight on/off
PRESS:Next value
HOLD: Stores or
edits current value PRESS: Modifies selection
HOLD: Enters data recall
mode (not available on
FLS-600)
PRESS: Toggles between
modulation values
Not present
in FLS-600
Keypad
PRESS: Enters setup
menu
HOLD: Erases data
PRESS: Switches between
measurement units
HOLD:Sets input power as
reference power (not
available on FLS-600)
PRESS:Switches between wavelengths
HOLD: Performs offset nulling
PRESS: Toggles between all available
wavelengths plus VFL (optional)
