Controlling the Source Remotely
25
Setting the Baud Rate
Setting the Baud Rate
The baud rate is a parameter related to RS-232 communication. It
determines the speed at which data is sent between the unit and a
computer, in bits per second (bps).
To change the baud rate for your remote communications:
1. Press the Setup key.
2. Use the up/down or left/right arrow keys to select Baud Rate. The
current setting is displayed.
3. Press ENTER, then use the up/down arrow keys to select the baud rate.
You can select 1200, 2400, 4800, 9600 or 19200 bps.
4. Press ENTER to confirm.
Refresh Rate
Backlight
Contrast
Video Mode
Exit
8 Hz
ON
STD
RS232 / GPIB
GPIB Addr.
Baud Rate
Flow Ctrl
RS232
N.A.
19200
Soft
