Setting CD/PMD Analyzer Source Parameters
12
Setting the Refresh Rate
Setting the Refresh Rate
You can define the refresh rate of the display.
To set the refresh rate:
1. Press the Setup key.
2. Use the up/down or left/right arrow keys to select Refresh Rate (the
item will be displayed in reverse video).
3. Press ENTER to access the Refresh Rate edit box.
4. Use the up/down arrow keys to set the refresh rate between 1/2 Hz,
1 Hz, 2 Hz, 4 Hz, 8 Hz and 16 Hz.
5. Press ENTER to confirm the new refresh rate.
Refresh Rate
Backlight
Contrast
Video Mode
8 Hz
ON
STD
Exit
RS232 / GPIB
GPIB Addr.
Baud Rate
Flow Ctrl
GPIB
12
N.A.
N.A.
