Controlling the Source

Remotely

You can control the CD/PMD Analyzer Source remotely either by:

³

a GPIB interface (through a GPIB cable connected to the GPIB port)

or

³

an RS-232 interface (through a serial cable connected to the serial
port).

Electro-Optical Engineering

R

GPIB IEEE 488.2

SH1, AH1, T6, L4, SR1, RL1, PP0, DC1, DT1, C0, E2

This device complies with part 15 of the FCC rules. Operation is

subject to the following two conditions: (1) this device may not cause

harmful interference and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Made in Canada

P/N

S/N

Ver.

Mfg.
date

QST-151

Serial Port

MODEL: GO
LR107723

100-240 V

50/60 Hz

2 A

F2AL250 V

C

US

Serial port (RS-232 DTE)
