IP Triple-Play Test Set 81
A Technical Specifications
I
MPORTANT
The following technical specifications can change without notice.
The information presented in this section is provided as a reference
only. To obtain this product’s most recent technical specifications,
visit the EXFO Web site at www.exfo.com.
IPTV TESTING SUITE
Supported video compression/standards MPEG2, MPEG4 part 2 and 10 (H.264/AVC), WM9
Video streaming control Video streaming (channels) detection
IGMP joins/leaves
Operation Through mode or stand-alone with STB IGMP emulation
Analysis and statistics IP layer analysis
Bandwidth usage per channel
IGMP packets
Set-top box (STB) traffic
Key IP video QoS parameters: packet loss, packet jitter, zap time
PCR jitter, PID statistics
Media delivery index (MDI) (option)
QoS pass/fail indicators
Multicast/unicast RTP/UDP
TCP/RTSP VOD
Graphic results Bandwidth usage
IP packet and PCR jitter histograms
VoIP ANALYSIS SUITE (VoIP TESTING)
Recognized signaling protocol Session initiation protocol (SIP) v2 (RFC)
Operation Through mode
Call monitoring/analysis IP layer call statistics
Call flow
Codec indicator (G.711, G.729, G.726, G.723)
Key VoIP QoS parameters: packet loss, packet jitter
QoS pass/fail indicators
Graphic results Delay distribution, jitter histogram
DATA ANALYSIS MODE
Login format Username and password using PAP or CHAP
IP options Routing functionality, NAT, DNS support
Ping Pings another device on the network
Device: gateway, destination IP address or URL
Configurable number of pings (1 to 99)
Packet size: 32 to 1500 bytes (32 is default)
Results: indicate packet size, packets sent/received, minimum/average/maximum round-trip times in milliseconds (ms)
Traceroute Determines the path used to reach device on the network
Timeout in seconds
Time to live (TTL) (default is 100 ms, maximum is 5 s)
Packet size: 32 bytes
Number of hops: 1 to 30 (default is 30)
Results indicate IP address of hop and round-trip time in milliseconds (ms)
HTTP speed test Downloads a Web page and indicates speed of download
Address: IP or URL
Protocol: HTTP
FTP speed test FTP upload, FTP download or both
Displays speed to upload and/or download a file
IP CONNECTIVITY SUPPORT
Supported functions DNS, DHCP, client/server, NAT, VLAN (802.1g)
