Introducing the AXS-200/650 IP Triple-Play Test Set
2 AXS-200/650
Typical Applications
Typical Applications
The AXS-200/650 allows you to test inside the customer premises over
Ethernet for applications, such as:
³
Auto test
³
CPE tests
³
IPTV analysis
³
Data analysis
³
VoIP analysis
Connector Description
The top of the AXS-200/650 module supports connections to a wide area
network (WAN) and a local area network (LAN).
LAN connector for
Ethernet output WAN connector for
Ethernet input
Headset connector
