Getting Started with Ethernet Testing
6 AXS-200/650
IP Tests
³
Configure Tests allows you to configure a series of test parameters
to verify applications, beginning with Auto Test.
³
Read Saved Result allows you to view the Read Results page.
Read Saved Results
The Read Results pane tab allows you to select a test type and view the
results of all the files previously saved.
Types listed include the following
Ethernet tests:
³
CPE Test
³
IPTV Analysis
³
Data Analysis
³
VoIP Analysis
To select the test type results to
read:
1. Press
to open the list.
2. In the list, press the up/down arrows to select the test type.
3. Press to confirm the selection.
