Modules & Options
7 - 36 3.75G/HSPA Module
7
5. Insert the USIM card as you would into your mobile phone.
6. Slide the SIMLOCK towards the hinge (in the opposite direction to the arrow
illustrated in
Figure 7 - 31 ) in order to release the lock and lift it up.
7. Insert the USIM card as illustrated in ( Figure 7 - 30 ) and close the SIMLOCK.
8. Lock the SIMLOCK by pushing it in the direction of the arrow in Figure 7 - 31 until
it clicks into the lock position.
9. Replace the covers and screws (reconnect the fan cable before screwing down
the bay cover for Model B computers - see sidebar for note on cover pins).
Figure 7 - 30
Insert the USIM
Card
Figure 7 - 31
SIMLOCK Lock
Cover Pins
Note that Model B has
cover pins that need to be
aligned with slots in the
case to insure a proper
cover fit, before screwing
down the bay cover.
Model A
Model B Model A
