18 - System Map: Right View

Concise User’s Guide

English

System Map: Right View

Figure 8 - Right View

1.

ExpressCard/54(34)
Slot

2.

7-in-1 Card Reader

3.

2 * USB 2.0 Ports

4.

RJ-45 LAN Jack

5.

External Monitor Port

ExpressCard Slot

The ExpressCard slot accepts either ExpressCard/34 or ExpressCard/54 formats.

7-in-1 Card Reader

The card reader allows you to use the most popular digital storage card formats:

MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) / MS Pro (Memory Stick Pro)
MS Duo (requires PC adapter) / Mini SD (requires PC adapter) / RS MMC (requires PC adapter)

1

4

3

2

3

5

1

4

3

2

3

5

Models A & B

Model C
