Page 33
System Map: LCD Panel Open - Model C 1 - 9
Quick Start Guide
1
LED Indicators
The LED indicators display helpful information about the current status of the computer.
*Note: The powered USB 3.0 port (see
) may be toggled on /off by means of the Fn + Power Button key
combination. When the powered USB port is on it will supply power (for charging devices only, not for operating devices) when the
system is off but still powered by the AC/DC adapter plugged into a working outlet, or powered by the battery with a capacity level
above 20% (this may not work with certain devices - see page
Icon
Color Models A&B or C
Description
Icon
Color
Description
Blue / White
Number Lock is Activated
Orange
The Battery is Charging
Blue / White
Caps Lock is Activated
Blinking Orange
The Battery has Reached Critically
Low Power Status
Blue / White
Scroll Lock is Activated
Green
The Battery is Fully Charged
Blue / White
Hard Disk Activity
Orange
AC/DC Power is Plugged In
Blue / White
The (optional) Wireless LAN
Module is Powered On
Blinking Orange*
The Powered USB Port is On*
Blue / Orange
The (optional) Bluetooth
Module is Powered On
Green
The Computer is On
Table 1 - 2 - LED Indicators
Blinking Green
The Computer is in Sleep Mode
