Specifications
D - 4 Specifications
D
Storage
One 12.7 mm Super Multi/Blu-Ray
Combo/Blu-Ray Writer SATA Optical
Device Drive (Factory Option)
One Changeable 2.5" 9.5 mm (h) SATA
(Serial) Hard Disk
Models A & B:
2nd HDD Caddy with SATA Inteface
(Factory Option for Models A & B)
Model C:
Up to Two (Factory Option) Changeable
2.5" 9.5 mm (h) SATA (Serial) Hard Disks
with RAID Level 0/1 Support
One mSATA Solid State Drive (SSD) with
SATA interface (Factory Option)
BIOS
One 48Mb SPI Flash ROM
AMI BIOS
Audio
High Definition Audio
S/PDIF Digital Output
Built-In Microphone
2 Built-In Speakers
1 Built-In Sub Woofer
THX TruStudio Pro
7.1CH Audio output supported by
headphone, microphone, S/PDIF & Line-
In Jack
Keyboard & Pointing Device
Full Size Winkey Keyboard with Numeric
Keypad and W/A/S/D Game Key
Markings
Built-In TouchPad (with Multi Gesture
Functionality)
Interface
One USB 2.0 Port
Three USB 3.0 Ports (Note: One
powered USB3.0 port (AC/DC)
One eSATA Port (SATA/Powered USB
3.0 Combo)
One Mini-IEEE1394a Port
One Display Port 1.1a
One DVI-I (Single Link) Out Port
One 1.4a HDMI-Out (High-Definition
Multimedia Interface) Port (with HDCP)
One Microphone-In Jack
One Headphone/Speaker-Out Jack
One S/PDIF Out Jack
One Line-In Jack
One RJ-45 LAN Jack
One DC-In Jack
Slots
Two Mini-Card Slots:
Slot 1 for WLAN or WLAN & Bluetooth
Combo Half Mini-Card Module with PCIe
and USB Interface
Slot 2 for mSATA SSD Full Size Mini-
Card Module with SATA Interface
