System Map: LCD Panel Open - Models A & B 1 - 7
1
System Map: LCD Panel Open - Models A & B
Figure 1 - 2
LCD Panel Open
1. Built-In PC Camera
2. LCD
3. LED Lock Indicators
4. Power Button
5. Speakers
6. LED Status Indicators
7. Keyboard
8. Built-In Microphone
9. TouchPad and
Buttons
10. Fingerprint Reader
(Optional)
Note that the Touchpad and Buttons
valid operational area is that indicat-
ed within the red dotted lines above.
2
1
8
9
7
3

Wireless Device
Operation Aboard
Aircraft
The use of any portable
electronic transmission de-
vices (e.g. WLAN or Blue-
tooth) aboard aircraft is
usually prohibited. Make
sure any wireless modules
are OFF if you are using the
computer aboard aircraft.
Use the appropriate func-
tion key combination to tog-
gle power to any wireless
modules, and check the in-
dicators to see if any mod-
ules are powered on or not
(see
Table 1 - 5, on page 1
- 15 / Table 1 - 2, on page 1
- 9 ).
6
5
4
5
10
Note that the keyboard for Models
A & B are different, and only Mod-
el A is pictured (see
Table 1 - 1,
on page 1 - 5 ).
