Drivers & Utilities
4 - 12 RAID Mode Configuration
4
17. After pressing <Enter> to select the array the following menu will appear.
18. First assign the type of RAID Mode you want to use by using the <Spacebar> to cycle through the array
types (Stripe or Mirror).
FastBuild (tm) Utility 2.01 (c) 2002-2005 Promise Technology, Inc.
[ Keys Available ]
[ Define Array Menu ]
A de
Array 1
Array 2 ---- ---- ---- ----
Array 3 ---- ---- ---- ----
Array 4 ---- ---- ---- ----
[ ↑] Up [ ↓] Down [Esc] Exit [Enter] Select
Figure 4 - 11
FastBuild Utility
(Define Array Menu)
FastBuild (tm) Utility 2.01 (c) 2002-2005 Promise Technology, Inc.
[ View Array Definition Menu ]
A de
A Stripe 2
S 128 KB y
C : D Dr ve Mode Cap p pac ty(MB) As t
: Mas FUJITSU MHT2030AT 30005
: Sla FUJITSU MHT2030AT 30005
[ ↑] Up [↓] Down [Esc] Exit [Space] Change Option [Ctrl - Y] Save
[ Keys Available ]
Figure 4 - 12
FastBuild Utility
(View Array
Definition Menu)
