Eurocom D900T PHANTOM - Manual (Page 167)

C
ATI Video Driver Controls
Attaching Other Displays C - 5
Attaching Other Displays
If you prefer to use a monitor or flat panel display, connect it to the DVI-Out
Port at the rear of the computer.
1. Attach your external monitor to the DVI-Out port (or TV/HDTV to the S-
Video Out port), and turn it on.
2. Select the Displays tab in the ATI Mobility Radeon properties.
3. Click the enable/disable button / for the display device you wish to
use.
4. Click Apply.
5. Click Yes to accept the settings and OK to save the changes.
6. Select One display as Primary , the remaining as the Clone (the
Clone may operate in either Clone Mode, or Extended Desktop Mode).
Function Key
Combination
You can use the Fn +
F7 key combination to
toggle through the dis-
play options:
• Notebook Only
• External Display
Only
• Notebook + External
Display
Make sure you give the
displays enough time
to refresh.
Figure C - 3
Display Settings
