Upgrading The Computer
Removing the Battery 6 - 3
6
Removing the Battery
If you are confident in undertaking upgrade procedures yourself, for safety reasons
it is best to remove the battery. Your computer may come with a 4 cell battery
,
or a 10 cell battery , depending on your purchase configuration.
1. Turn the computer off, and turn it over.
2. Slide the latch in the direction of the arrow (it will remain in place).
3. Slide the latch in the direction of the arrow, and hold it in place.
4. Slide the battery out of the computer in the direction of the arrow .
10 Cell Battery
Warning
Please be careful when
using the 10 cell battery.
The battery is heavy and
extends beyond the
case of the computer.
Moving the battery, or
exposing it to shock or
vibration may interrupt
the battery contacts and
cause the computer to
shutdown.
Figure 6 - 1
Battery Removal
4
5
1
2
3
3
1
2
4
1
2
3
5
