1 - 12 System Map: Bottom View

Quick Start Guide

1

System Map: Bottom View

2

3

1

4

1

5

6

Figure 1 - 7 - Bottom View

1.

Vent/Fan Intake/Outlet

2.

Battery

3.

Optical (CD/DVD) Device Drive Release
Cover

4.

Component Bay Cover

5.

Hard Disk Drive Bay Cover

6.

Speaker

CPU

The CPU is not a user serviceable part. Open-
ing this compartment, or accessing the CPU in
any way, may violate your warranty.

Overheating

To prevent your computer from overheating
make sure nothing blocks the vent(s)/fan in-
take(s)/outlet(s) while the computer is in use.
