Pc card slot, Inserting and removing pc cards, Pc card slot -7 – Eurocom M620NC TITANIUM User Manual
Page 43: Inserting and removing pc cards -7
Features & Components
PC Card Slot 2 - 7
2
PC Card Slot
The computer is equipped with a PCMCIA 3.3V/5V slot for one type II PCMCIA
CardBus PC Card Slot. Make sure you install the PCMCIA/Card Reader driver (see
“PCMCIA/CardReader” on page 4 - 9
).
Inserting and Removing PC Cards
• Align the PC Card with the slot and push it in until it locks into place.
• To remove a PC Card, simply press the eject button
next to the slot.
PC Card Slot Cover
Make sure you keep the
cover in the PC Card
slot when not is use.
This will help prevent
foreign objects and/or
dust getting in to the PC
Card Slot.
Figure 2 - 5
Left View
1.
PC Card Eject
Button
1
1
