1 - 10 System Map: Left View
Quick Start Guide
1
System Map: Left View
1
4 2
5
6
3
Mini-IEEE 1394 Port
The Mini-IEEE 1394 Port only supports SELF POWERED IEEE 1394 devices.
4-in-1 Card Reader
The card reader allows you to use the most popular digital storage card formats:
MMC (MultiMedia Card) / SD (Secure Digital) / MS (Memory Stick) /
MS Pro (Memory Stick Pro)
Figure 1 - 5 - Left View
1. Vent/Fan Intake/Outlet
2. External Monitor Port
3. 1 * USB 2.0 Port
4. Mini-IEEE 1394 Port
5. 4-in-1 Card Reader
6. PC Card Slot
Overheating
To prevent your computer
from overheating make sure
nothing blocks the vent(s)/
fan intake(s)/outlet(s) while
the computer is in use.
