Note: This is a good time to test TCP/IP communication between the PC and the

i

.LON 1000

by

pinging the

i

.LON 1000

from the PC, and by pinging the PC from the

i

.LON 1000.

Open the Windows Start menu, point to Programs, and choose the MS-DOS Prompt to open a DOS box.
Type: ping 10.1.0.170. From the

i

.LON 1000

console application type: ping .

See your TCP/IP network administrator for information on how to use the ping command.

3

Recall the examples described in Chapter 3 of the Getting Started with the
L

ON

W

ORKS

System Starter Kit

. The following steps show how to add an

i

.LON

1000

to the network that was created in that chapter.

a) Start the LonMaker tool and restore the final solution file from the Getting

Started with the L

ON

W

ORKS

System Starter Kit

. The file name is

LonPoint PID.zip

. Although the LonMaker tool will prompt you to re-

commission all the devices in the drawing, it is not necessary to do so at
this time.

b) Once the network and drawing are restored, open them by clicking the

Open Network

button. When prompted, be sure to select “OnNet” for

the LonMaker management mode.
The LonMaker tool again will prompt you to recommission all the devices in
the drawing, it is not necessary to do so at this time.

The LonMaker drawing should look like figure 2.3

Figure 2.3 Sample LonMaker Drawing
