Specifications - 152
RT100 Powershift Operator’s Manual
M912 Offest Trencher
CMW
H1 Transport height
RT100 with 38 x 18.00-20 tires 124 in 3.2 m
K Distance between trencher positions 26 in 660 mm
L2 Transport length 112 in 2.8 m
L Headshaft overhang 40 in 1.0 m
N Soil discharge reach 33 in 840 mm
Attachment weight 3600 lb 1633 kg
Operation U.S. Metric
Headshaft speeds
Ratio extra low 141-211 rpm 141-211 rpm
Ratio low 155-232 rpm 155-232 rpm
Ratio standard 171-255 rpm 171-255 rpm
Digging chain speeds
Ratio extra low 437-654 ft/min 133-199 m/min
Ratio low 481-720 ft/min 147-219 m/min
Ratio standard 530-793 ft/min 162-242 m/min
Dimensions U.S. Metric
