Ditch Witch RT100 - Manual (Page 149)

Specifications - 148
RT100 Powershift Operator’s Manual
RT100 Tractor
CMW
Unless otherwise specified, all figures are for standard equipment only.
Specifications are called out according to SAE recommended procedures. Specifications are general and subject to change without
notice. If exact measurements are required, equipment should be weighed and measured. Due to selected options, delivered
equipment may not necessarily match that described.
Hydraulic System U.S. Metric
Ground drive pump capacity at 2300 rpm 9.7 gpm 36.7 L/min
Ground drive pump relief pressure 4000 psi 276 bar
Auxiliary pump capacity at 2300 rpm 13.6 gpm 51.5 L/min
Auxiliary pump relief pressure 2500 psi 172 bar
Fluid Capacities U.S. Metric
Fuel tank 38 gal 144 L
Engine oil 8.5 qt 8 L
Hydraulic reservoir 24 gal 91 L
Hydraulic system 29 gal 110 L
Cooling system 10.9 qt 10.3 L
Transmission fluid 9.5 qt 10.5 L
Battery (2 used)
Group 34H, SAE res. cap 120 min., SAE cold crank @ 0° F (-18° C), 800 amp
Auxiliary power outlet - 12 volt, 10 amp
Vibration Level
Vibration transmitted to the operator’s hand/arm and whole body during normal operation is 6.4 and
2.44 meters per second squared respectively.
Operator seat per ISO 7096.
Noise Levels
Operator 93 dBA sound pressure per ISO 6394
Exterior 108 dBA sound power per ISO 6393.
