Specifications - 146
RT100 Powershift Operator’s Manual
RT100 Tractor
CMW
Operation U.S. Metric
Forward speeds
Low/Low 0.44 mph 0.71 km/h
Low 6.4 mph 9.91 km/h
High 9.5 mph 14.85 km/h
Reverse speeds
Low/Low 0.44 mph 0.71 km/h
Low 6.0 mph 9.65 km/h
High 8.89 mph 14.31 km/h
Vehicle clearance circle (SAE) wall to wall with backfill blade
Front steer only 35 ft 11 m
Front and rear steer 21 ft 6 m
Ground clearance 14 in 355 mm
Basic unit weight 8880 lb 4028 kg
Maximum allowable tractor weight 19,300 lb 8754 kg
Front counterweight 1300 lb 590 kg
Backfill Blade U.S. Metric
Blade width 80 in 2.0 m
Blade height 18 in 457 mm
Lift height above ground 20 in 508 mm
Blade drop below ground 14 in 356 mm
Maximum swing angle (left/right) 25° 25°
Tilt angle (up/down) 12° 12°
