Multi-Appliance Manual Control
Navigating the Controls
I CONS
The operating icons will be displayed relative to the
installed product.
1.
Bars Indicator evaporative cooling fan speed.
2. Water Droplets indicate the evaporative cooler
pump is on.
3. Fan indicates the evaporative cooler or central
heater unit fan is operating.
4. Flame indicates that the thermostat is calling for
heat from the ducted central heater
5. Snow Flake indicates the Dual Cycle refrigerated
air conditioner is calling for cooling
6.
Padlock means the control functions are locked by
the Child Lock.
.
C HILD L OCK
This function is designed to be a simple mechanism
to lock the control to prevent unnecessary
adjustments to the system. When the lock is engaged
there will be no system functions available
•
•
To engage the Child Lock press and hold the UP
and DOWN buttons together for 3 seconds. The
padlock symbol will be displayed on the screen
when the child lock has engaged.
To remove the child lock press and hold the UP
and DOWN buttons together for 3 seconds. The
padlock symbol will disappear from the screen
display when the child lock has been removed.
