INSTALLATION / INSERT UNIT / VENTING
1. The LR-01 is designed for both new installations and as an insert into existing fireplaces. The LR-01 is
NOT designed to be installed without proper vent pipe. Proper venting can be achieved by installing a
3” (less than ten feet) or 4” (more than ten feet) TYPE PL double wall vent pipe or listed TYPE “L”
chimney liner. A listed single wall stainless steel liner may be used if installing the LR-01 into an
approved wood burning chimney. The vent pipe may be run to the top of the existing chimney or to a
point 18” above the damper of the existing chimney. Flue pipe manufacturer’s instructions should be
consulted for further detailed pipe installation instructions. Most flue pipe manufacturers will provide
detailed drawings of venting plans, which meet or exceed code requirements. NOTE: Follow all vent
manufacturers vent pipe instructions without deviation. Check local codes to ensure conformance.
2. WARNING: DO NOT operate any pellet stove unless connected to proper flue system. Do not
connect the LR-01 to a chimney flue serving another appliance.
3. Flue pipe joints need to be joined tightly to ensure air tight venting with at least (3) sheet metal screws
and sealed with RTV silicone or approved aluminum flue pipe tape.
4. FIGURE 8 shows a sample of a factory recommended method of flue pipe installation. The vent pipe is
extended just above the top of the existing chimney (consult local ordinances for code requirements.)
The flue pipe must be fitted with a proper pellet flue cap. A storm collar and flashing should be
installed to seal off the chimney opening.
