Specifications & Board Interfaces 5
cPCI-6S10
2 Specifications & Board Interfaces
2.1 cPCI-6S10 Specifications
Standards and Interfaces
Mechanical & Environmental
Table 2-1: cPCI-6S10 Specifications
CompactPCI
Standard
PICMG 2.0 CompactPCI Rev. 3.0
PICMG 2.9 System Management Bus Rev. 1.0
PICMG 2.16 Packet Switching Backplane Rev.1.0
Switch Fabric,
PHY
• Broadcom BCM56150 24-port Gigabit Ethernet switch with
two 10G SFP+ uplink ports
• Broadcom BCM54685 Octal-port 10/100/1000BASE-T PHY
• Broadcom BCM5221 10/100BASE-TX management port
Networking
• 3x 10/100/1000BASE-T ports to front panel (BCM56150)
• 20x 10/100/1000BASE-T ports to rear (BCM56150, 9x to J3,
11x to J5)
• 1x inter-switch link 1000BASE-T
• 2x 10G SFP+ ports for uplink through BCM56150
• 1x 10/100BASE-TX for management
Front Panel IO
3x 10/100/1000BASE-T RJ-45 ports
2x 10G SFP+ interfaces for uplink interface
1x 10/100 RJ-45 management port
1x UART port via RJ-45
Rear IO 20x 10/100/1000BASE-T ports to J3 and J5
Dimensions 233.35mm x 160mm (L x W), 6U 4HP single slot
Operating
Temp. Standard: 0°C to 60°C
ETT version upon request
Storage Temp. -50°C to 100°C
Humidity 95% non-condensing
Shock 15G peak-to-peak, 11ms duration, non-operating
Vibration Non-operating: 2G rms, 5 to 500 Hz, each axis
Compliance CE, FCC Class A
Power
Consumption
TBD
NOTE: NOTE:
Specifications are subject to change without prior notice.
