44 Board Interfaces
CompactPCI J5 Pin Assignment
Table 4-17: CompactPCI J5 Connector Pin Definition
Pin Z A B C D E F
1 GND PCIE-TX0+ PCIE-TX0- GND PCIE-RX0+ PCIE-RX0- GND
2 GND PCIE-TX1+ PCIE-TX1- GND PCIE-RX1+ PCIE-RX1- GND
3 GND PCIE-TX2+ PCIE-TX2- GND PCIE-RX2+ PCIE-RX2- GND
4 GND PCIE-TX3+ PCIE-TX3- GND PCIE-RX3+ PCIERX3- GND
5 GND GND GND GND GND GND GND
6 GND CLK0+ CLK0- GND RESET# NC GND
7 GND NC NC NC NC NC GND
8 GND NC NC NC NC NC GND
9 GND GPIO0 GPIO1 GPIO2 GPIO3 GPIO4 GND
10 GND NC NC GND NC NC GND
11 GND NC NC GND NC NC GND
12 GND NC NC NC NC NC GND
13 GND NC NC NC NC NC GND
14 GND NC NC GND NC NC GND
15 GND NC NC NC NC NC GND
16 GND MTR0# INDEX# GPIO6 FDEDIN# DENSEL# GND
17 GND DIR# NC GPIO7 DSEL0# NC GND
18 GND TRK0# WGATE# GPIO9 WDATA# STEP# GND
19 GND DSKCHG# HDSEL# NC RDATA# WRPORT# GND
20 GND NC NC GND NC NC GND
21 GND NC NC GND NC NC GND
22 GND NC NC NC NC NC GND
GPIO
PCI-Express x4
Floppy
